SUPERIOR THERMAL PERFORMANCE
High-airflow mesh front and vertical airflow layout ensure efficient heat dissipation during demanding workloads or gaming sessions.
INTEGRATED GPU SUPPORT BRACKET
Includes a height-adjustable GPU holder to minimize sagging and protect your graphics card long term.
Extended desiqn at the bottom of the panel to seal the hardware rack holes.
Stay up to date. Ready for the latest games and highest performing Next-Gen GPUs.
Form Factor: | Mid-Tower |
|
Chassis: | SPCC :0.5mm |
|
PSU Form Factor | Bottom/ATX |
|
M/B Form Factor: | ATX、M-ATX、ITX |
|
Front Panel: | Plastic + Mesh |
|
Top Panel: | Metal |
|
Side Panel: | Left: | Tempered Glass (Tool-free) |
Right: | Metal cover |
Internal Drive Bay(s): | 3.5" (HDD): | *Up to 2 |
2.5" (SSD): | *Up to 2 |
2*3.5HDD+1*2.5SSD or 1*3.5HDD+2*2.5SSD |
|
I/O: | Buttons: | *2 (POEWR, RESET or LED MODL) |
USB 2.0 Port(s): | *0 |
USB 3.0 Port(s): | *2 |
Type C Port(s): | *1(TYPE-C GEN2) |
Audio Support: | *1(Combo AUDIO) |
Cooling Fan Support: | Front: | 3x140mm (Tornado-T14) |
Top: | 3x120mm ,2x140mm (Fan optional) |
Rear: | 1x120mm (Tornado-T12) |
Bottom: | *0 |
M/B Cover： | *2x120mm (Fan optional) |
PSU Cover： | *3x120mm (Fan optional) |
Water Cooling Support (Radiator Size): | Front: | *0 |
Top: | 120mm, 140mm,240mm,280mm,360mm |
Rear: | 120mm |
M/B Cover： | *0 |
Dust Cover: | Dust mesh on the bottom and top |
|
Slots: | *7 |
|
Carton & Logo: | GAMEMAX |
|
Dimensions: | Chassis: | (L)458*(W)220*(H)446mm |
Full Case (Inc Fascia): | (L)483*(W)220*(H)458mm |
Carton: | (L)500*(W)277*(H)551mm |
Net Weight(kg): | TBU |
Gross Weight(kg): | TBU |
VGA Support: | up to 420mm (inside the front cover w/o fan) |
|
Vertical Graphics Support | No |
|
CPU Cooler Height: | up to 175mm |
|
SPS Length: | up to 240mm |
|
Cable Management Depth: | 21mm |
|
